TRU45T 700c 45mm carbon road bike tubular rims 25mm wide

Model: TRF45S
Rim weight:400g+/-15gr XC
Rim out wide: 28mm
Rim inner wide: 21mm
Rim depth: 45mm
Description:Product can be used on road / CX bike wheels

EMAIL


Item No.: TRU45T

Size: 700C

Material: Full Carbon Toray T700 & T800

Type: Tubular

Weight: Standard 380±15g, Flyweight 335±15g

ERD: 550mm

Inner Width:  25mm

Depth:  45mm

Brake system: Disc / Rim brake

Max Spoke Tension:  140kgf

Max Weight Limit:  Standard 135kg/ 298lbs, Flyweight 90kg/ 198lbs

Braking  System: Disc Brake

Applicable Bicycle: XC / AM Mountain Bicycles

Appearance: UD/3K/12K

Finishing: Matte/Glossy

Standard: En Standard

Assembly Hole Dia: 8.5mm

Spoke Hole Dia: 4.5mm

Valve Hole Dia: 6.5mm

Roundess:<0.3mm



Features:

  • * This 700C disc rims 45mm deep tubular is aerodynamic U rim shape, better handling in crosswinds condition and faster riding.

  • * Super lightweight, rim constructed with premium Toray T700 & T800 carbon fiber, best strength to weight ratio with no expense spared.

  • * Carbon Strip Reinforcement. Use unique carbon strip to strengthen the spoke tension and stabilize rim structure and reduce the rim weight.

  • * Smooth Wall Tec. No folded prepreg during curing, smooth both inside and outside rim wall to reduce potential quality issues.

  • * Angled spoke holes allows the nipple to pull straight in line with the spoke for reduced stress, this results in fewer broken spokes and nipples.
