Aero Disc Brake Carbon Fibre Road Bike Frameset TFR63

Aero carbon road disc brake bike frame
142 x 12mm, 100 x 12mm
49/52/54/56/59 CM
BB386
700*32C

EMAIL

Model: TFR63

Product Name: Full Carbon Fibre Disc Brake Road Frame

Carbon Material: T800 toray carbon fiber

Carbon Weave: UD

Frame height: 490/520/540/560/590 mm

Bottom Bracket:  BB386

Finish: Matte or Glossy

Head Tube: FSA NO. ACB1 42(1-1/2"-1-1/2"), 51.8mm

Seatpost: Aero

Suitable Derailleur: Di2 or Mechanical

Weight: Frame 1220g±30g (54cm),Fork 402g ,Seatpost 244g

Braking System: Disc Brake (160mmm)

Seatpost insertion length: 7cm to 12cm

Frame Thru-axle: 142* 12mm

Fork Thru-axle: 100* 12mm

Max Tire Size: 700c x 32mm

The set Included:

Frame+Headsets+ Seatpost Clamp+Thru Axle Rod+ Aluminum parts

Warranty: 2 years
